Stroboscopes
LED Mobile stroboscopes
from Macrosys are an effective substitute for the 220 V operated wired handy stroboscopes. They can be carried from station to station and from one machine to another without any complications of sparks and wires.
Evenly distributed weight and a comfortable holding posture lets the operator have a firm strong grip and single handed operation so that with the other hand he can work on the cylinder
Power Button Enables and disables the main circuit.
Frequency & Intensity
Lets you control frequency as well as the intensity of the Led Mobile. Intensity feature has been added to increase the clarity in reading small words. Also increasing/decreasing intensity helps control the light reflecting depending upon the substrate.
Battery Management system
Equipped with a battery management circuit that enhances battery life.
Points to know for using Led Mobile stroboscope
- Press ‘ON’ the main power button on the lower backside.
- Then press the trigger button on the front grip that will trigger the Led for 90 seconds.
- Adjust the frequency with the frequency Knob.
- Adjust the intensity of the Led with the intensity knob.
- Turn ‘OFF’ the power button when not in use.
NOTE: For reading smaller words, kindly lower down the intensity.
Battery monitoring system
- On the backside of Led mobile stroboscope, there is an indicator, which glows when the battery is low.
- When charger is plugged with low battery, a red Led will glow on charger and when the Led mobile stroboscope gets fully charged the indicator turns green.
Portable
- No wires.
- Easy to carry from station to station.
- Designed with a easy grip that gives you a firm hold.
Battery operated
- Li-ion battery
- A controller for Battery monitoring – that indicates battery low and full indications
Single Led based
- Specially designed Led that give lumens equivalent to 40 Led’s.
- With a CCT of 6500K and standard CRI it gives the true image of moving web
| CCT (correlated color temperature) of Led | 6500K |
| CRI (Color rendering Index) of LED | Standard |
| Light Flux | Over 2100 lumens |
| Coverage | 250 mm x 200mm from a distance of 100mm |
| Led Life | >50,000 hrs |
| Operating frequency | 10-70 Hz |
| Can be used upto speed of | 600 meters/minute |
| Battery type | Li-ion |
| Battery life | 450-500 cycles |
